Fastest Manual Jackplate Out There...Adjusts On The Fly
NEW MODELS WITH UPGRADED JACK With enhanced speed and lifting power
On The Fly Jack Plates are the fastest manual jack plates on the market. Our jack plates can be raised and lowered by a manual handle while on the water within seconds from top to bottom. The biggest benefit of our jack plate is TIME because every second counts out on the water! Cut your time adjusting your manual jack plate from 20 minutes to just seconds!
NEW Larger Gear Ration - The upgraded Manual Jack features a higher gear ratio for effortless motor lifting - increasing the speed and ease of motor adjustment.
- MAX RISE (travel): 5 1/2 inches of travel. Plus, depending on where you mount the jack you can get up to 7 3/4 inches of rise.
Sizes:
- Standard - For up to 30hp motors - 150 lb. weight limit (for motors without factory trim and tilt)
- Large - For up to 50hp motors - 230 lb. weight limit (for all motors WITH factory trim and tilt)
- To View Electric Switch Operated Version CLICK HERE
INVENTORY STATUS:
Standard & Large Available In Stock - Ships out within 1-2 Days
• Our custom manual jack mounts inside the jack plate housing
• 3 year warranty on the jack plate housing
• 1 year warranty on the jack
• Pre-drilled for transom mounting
• Jack plate housing made in the USA
MAX RISE (travel): 5 1/2 inches of travel. Plus, depending on where you mount the jack you can get up to 8 inches of rise.
STANDARD JACK PLATE DIMENSIONS - Weight 23 lbs.
- Height – 10 1/2”
- Width (Transom Side) – 12 ½”
- Width (Motor Side) – 13 ¼”
- Set Back – 5” (total length from of transom side to the back of the motor slide)
- Motor Plate Height – 12 ½”
- Motor Mounting Plate (Inside Brackets) – 10 ¾”
LARGE JACK PLATE DIMENSIONS - Weight 30 lbs.
- Height – 10 1/2”
- Width (Transom Side) – 16 1/8”
- Width (Motor Side) – 17”
- Set Back – 5 1/4” (total length from of transom side to the back of the motor slide)
- Motor Plate Height – 13 3/4”
ACCESSORIES NOT INCLUDED: Transom mounting accessories are not included in purchase. On The Fly Jack Plates recommends
- 4 each ½”- 3 1/2” long bolts – stainless steel
- 4 each ½”- lock nuts – stainless steel
- 8 each 1/2’”-flat washers – stainless steel
- Motor Clamp Spacers
***PATENTED***
